Mill is a Micro ATX format chassis. Its design is discreet but original, since it combines smooth material with grid texture.
Its structure allows installing cooling systems. A perfect chassis for users who looking for performance and simplicity in the same product.
P/N:52079 · EAN:6940533541790

MILL Micro ATX
– Includes MATX 500W power supply.
– Includes USB 3.0 and USB 2.0 connection.
– Design that combines smooth panels with grid texture.
PRODUCT
PC Case Micro ATX MILL PN:52079
TYPE CHASSIS
Micro ATX
DIMENSIONS
390 (L) x 175 (W) x 350 (H) mm
WEIGHT
3,075 kg
COLOUR
Black
MATERIAL
SGCC
SIDE PANEL
Metal
EXPANSION SLOT
4 Normal
BAY 5,25” INT/EXT
0 / 1
BAY 3,5” INT/EXT
2 / 1
BAY 2,5” SSD INT/EXT
3 / 0
CONNECTOR
USB 2.0 x 2 / USB 3.0 x 2
MICROPHONE / HD AUDIO
Yes / Yes
FPOWER SUPPLY ADMITTED
Included ATX 500W
COMPATIBILITY AIR COOLING
Yes
MAX CAPACITY OF FANS
2 x (80 mm) or (90 mm)
CPU COOLER MAX HEIGHT
150 mm
WIDTH MAX GPU / PCI CARD
320 mm
VGA COMPATIBILITY
Yes (Normal Profile)
MAX DIMENSION ADMITTED GRAPHIC CARD
320 mm
PACKAGING
DIMENSIONS
435 (L) x 211 (W) x 390 (H) mm
WEIGHT
4,7 kg
CUBIC CAPACITY
0,0358 m3
COLOUR
brown
MATERIAL
Paperboard
PACKAGE CONTENT
Pc Case Micro ATX / Power Supply / Screws
CERTIFICATIONS
CE / ROHS
