Designed for both horizontal and vertical use, it can be placed in tight spaces where a powerful PC is needed. Within its elegant, compact and minimalist design, it is compatible with Micro-ATX and Mini-ITX motherboards; it has room for graphics cards up to 240mm and features 2 high-speed usb 3.0 connectors.
P/N:UK52106 · EAN:6974560220519
MULTIPLE CONNECTION POSSIBILITIES
With a state-of-the-art Slim chassis, the Micro ATX UK3002 box has two high-speed USB 3.0 connectors, two USB 2.0 and audio connections on its front. In addition, as a novelty, it gives us the option of installing a Smart Card reader or an optical reader up to 9.55 mm.
PC CASE SLIM UK3002 Micro ATX
– Compact design of 8.3 litres.
– Front with 2 USB 2.0 and 2 USB 3.0.
– Admits motheboards Micro-ATX and Mini-ITX.
– Option to install Smart Card reader or Optical reader.
SMALL SIZE, LARGE CAPACITY
This version of micro ATX box stands out for its compact and minimalist design. With a capacity of 8.3 Liters, the UNYKAch UK3002 allows us to install Micro-ATX or Mini-ITX motherboards and has space to install low-profile graphics cards up to 240 mm. Its design allows us to place it standing or horizontally; this makes the UNYKAch UK3002 specially optimised for use in places with numerous workstations, such as public administrations, schools, large offices or in small desks where space is a plus.
PRODUCT
Pc Case Slim Micro ATX UK3002 8’3 Litres PN:UK52106
TYPE CHASSIS
Micro ATX 8’3 Litres
DIMENSIONS
272 (L) x 95 (W) x 335 (H) mm
DIMENSIONS WITHOUT FRONT
260 (L) x 95 (W) x 335 (H) mm / 8’3 Litres
WEIGHT
1,90 kg
COMPATIBLES MOTHERBOARD
Micro ATX / ITX
COLOUR
Black
MATERIAL
SGCC / ABS
EXPANSION SLOT
3
BAY 5,25” INT/EXT
0 / 0
BAY 3,5” INT/EXT
0 / 0
BAY 2,5” SSD INT/EXT
2 / 0
CONNECTOR
2 x USB 2.0 / 2 x USB 3.0
BAY SMART CARD / ODD
Optional (If you install a Smart Card reader, you cannot install a 9.55 mm Optical Reader, and if you install a 9.55 mm Optical Reader, you cannot install a Smart Card reader)
MICROPHONE / HD AUDIO/span>
Yes / Yes
POWER SUPPLY ADMITTED
TFX
CPU COOLER MAX HEIGHT
60 mm
VGA COMPATIBILITY
240 mm (with HDD support)
PACKAGING
DIMENSIONS
368 (L) x 149 (W) x 386 (H) mm
WEIGHT
2,23 kg
CUBIC CAPACITY
0,0211 m3
COLOUR
Brown
MATERIAL
Paperboard
PACKAGE CONTENT
Micro ATX Case 8’3 liters / HDD Adapter / Screws
CERTIFICATIONS
CE / ROHS
TECHNICAL SHEET-GALLERY
PC Case Slim Micro ATX UK3002 8’3 Litres PN:UK52106
MANUAL
–
DRIVERS
–
OTHERS
–
MASTER BOX DIMENSIONS
368 (L) x 149 (W) x 386 (H) mm
MASTER BOX WEIGHT
2,23 kg
UNITS PER MASTER BOX
1
UNITS PER AMERICAN PALLET
100
UNITS PER EUROPEAN PALLET
–
Recommended
