Redundant Power Supply
P/N: PSUCRPS800WR · EAN: 6940533544289
The professional range of redundant power supplies from UNYKAch is designed with interchangeable modules. These two power modules, in normal situation, automatically share the load for optimum efficiency. If a power module fails, the remaining unit immediately takes over the power supply, while the damaged unit can be replaced without stopping the operation, avoiding the risk of data loss or system interruption.
The redundant power supply CRPS 800W has an efficiency of 92%, which makes it equivalent to the 80 Plus Platinum certification.
On the other hand, the CRPS 550W / 800W redundant power supply comes with an adapter that allows it to become the Standard ATX format.
PRODUCT
VERSION
INTEL 2.3
CHASSIS DIMENSIONS
225 (L) x 75 (W) x 84 (H) mm
CHASSIS WEIGHT
2,806 kg
COLOUR
Silver
CONTROL OF ENERGY
- Nominal Power Supply Voltage: 800W
- Maximum AC Input Current 100-240V / 50-60 Hz Serial: PSUCRPS800WR
- Maximum Output Current +3,3V: 24 A
- Maximum Output Current +5V: 38 A
- Maximum Output Current +12V1: 45 A
- Maximum Output Current +12V2: 45 A
- Corriente Máxima de Salida -12V: 0,5 A
- Maximum Output Current +5Vsb: 3 A
SATA CONNECTOR
3 x 650 mm / 3 x 500 mm
24 PIN CONNECTOR
1 x 450 mm
8 PIN CONNECTOR PCI-E
1 x 400 mm
4 + 4 PIN CONNECTOR
1 x 300 mm
EPS 12V CONNECTOR
1 x 470 mm
MOLEX CONNECTOR
3 x 500 mm / 3 x 650 mm
POWER SUPPLY
Incluye 2 Power Supplies CRPS 800W
PACKAGING
DIMENSIONS
225 (L) x 75 (W) x 84 (H) mm
WEIGHT
2,806 kg
CUBIC CAPACITY
0,0016 m3
COLOUR
Transparent
MATERIAL
BULK
PACKAGE CONTENT
Chassis / 2 Redundant Power Supplies / Screws /ATX Adapter
PROTECTIONS & CERTIFICATIONS
CE / OVP / UVP / OCP / SCP / OPP
EFFICIENCY & CERTIFICATIONS
ROHS / EN60950 / TÜV / 92% Efficiency
WARRANTY
3 Years
