Power Supply
1U STANDARD UKPSU1U 250W

P/N:UKPSU1U40004 · EAN:6940533544630
This power supply in 1U format specially designed for the professional sector.
Built with high quality materials, it provides a power of 250W.
It includes a 40 mm fan for optimal cooling of all components, as well as it contains multiple protection systems, such as safety against overvoltage, low voltage, overcurrent and short circuits.
1000rpm-apfc-ac-120w
Power Supply FLEX Standard 250W UKPSU1U40004

PRODUCT

VERSION
INTEL 2.3

TYPE CHASSIS
1U Standard

DIMENSIONS
195 (L) x 100 (W) x 40 (H) mm

WEIGHT
990 g

COLOUR
Silver

CONTROL OF ENERGY

  • Nominal Power Supply Voltage: 250W
  • Maximum AC Input Current 100-230V / 50-60 Hz Serial: UKPSU1U40004
  • Maximum Output Current +3,3V: 16 A
  • Maximum Output Current +5V: 12 A
  • Maximum Output Current +12V1: 18 A
  • Maximum Output Current +12V2: 10 A
  • Maximum Output Current -12V: 0,5 A
  • Maximum Output Current +5Vsb: 2 A

POWER FACTOR
APFC

CAPACITORS
Chinese

8 PIN (4 + 4 PIN) CONNECTOR
1 x 420 mm

20 + 4 PIN CONNECTOR
1 x 400 mm

FDD CONNECTOR
1 x 890 mm

MOLEX CONNECTOR
1 x 560 mm / 1 x 710 mm

SATA CONNECTOR
2 x 400 mm / 1 x 560 mm / 1 x 700

RAIL
Dual 12V

FAN
40 mm

PACKAGING

DIMENSIONS
195 (L) x 100 (W) x 40 (H) mm

WEIGHT
990 g

CUBIC CAPACITY
0.0007 m3

COLOUR
Trasparent

MATERIAL
Bag

PACKAGE CONTENT
Power Supply 1U Standard

PROTECTIONS & CERTIFICATIONS
OVP / UVP / OCP / SCP / OTP

EFFICIENCY & CERTIFICATIONS
CE / ROHS

DOWNLOAD

TECHNICAL SHEET
Power Supply 1U Standard 250W PN:UKPSU1U40004
