Power Supply
CRPS 550W 92% EFFICIENCY

P/N:PSUCRPS550W · EAN:6940533544296
The professional range of redundant power supplies from UNYKAch is designed with interchangeable modules.
The CRPS 550W power supply can be connected both hot and redundant, besides it has an efficiency of 92% which makes it equivalent to the 80 Plus Platinum certification.
CRPS-550-2300RPM-APFC-92EFF
Power Supply CRPS 550W 92 Efficiency PSUCRPS550W

PRODUCT

VERSION
INTEL 2.3

DIMENSIONS
185 (L) x 73 (W) x 40 (H) mm

WEIGHT
829 g

COLOUR
Silver

CONTROL OF ENERGY

  • Nominal Power Supply Voltage: 550W
  • Maximum AC Input Current 100-240V / 50-60 Hz Serial: PSUCRPS550W
  • Maximum Output Current +12: 45 A
  • Maximum Output Current +12Vsb: 3 A

POWER FACTOR
APFC

CAPACITORS
Taiwanese

RAIL
Single

FAN
40 mm

RPM
2300 ± 10 %

PACKAGING

DIMENSIONS
185 (L) x 73 (W) x 40 (H) mm

WEIGHT
829 g

CUBIC CAPACITY
0,0005 m3

COLOUR
Transparent

MATERIAL
BULK

PACKAGE CONTENT
Power Supply / Screws

PROTECTIONS & CERTIFICATIONS
CE / OVP / UVP / OCP / SCP / OPP

EFFICIENCY & CERTIFICATIONS
ROHS / EN60950 / TÜV / 92% Efficiency

WARRANTY
3 Years

DOWNLOAD

TECHNICAL SHEET-GALLERY
Power Supply 550W 92% Efficiency PN:PSUCRPS550W

MANUAL
–

DRIVERS
–

OTHERS
Product link in ICECAT

RECOMMENDED

*All specifications and features, as well as color and software versions, may subject to manufacturing changes.
*The availability of the products may vary according to the market. Consult your supplier for promotions and special offers.
*All brands are registered according to the law.
